• HDMI version 1.3 and HDCP version 2.0 compliant
• Supports 1080p and 720p video, plus 2-channel audio
• One source feeds an almost unlimited number of HDTVs (127)
• Uses off-the-shelf gigabit IP switches for extension and distribution
• Plug-and-play operation - no programming or setup required
• Extends 1080p HDMI signals up to 120m over a single UTP Cat5e/6 cable
• Cable runs can be extended another 120m by adding a Gigabit Ethernet switch
• Traffic can unicast , multicast or broadcast for different applications
• With IR Control function ,it allows you control back the source at the end of destination
• Maximum 3 layers of ethernet switches could be passed through
| Operating Temperature Range | -5 to +35℃(+23 to +95℉) |
| Operating Humidity Range | 5 to 90%RH (No Condensation) |
| Input Video Signal | 0.5-1.0 Volts P-P |
| Input DDC Signal | 5 volts p-p(TTL) |
| Support Video Format | DTV/HDTV:480i/576i/480P/576P/720P/1080i/1080P |
| HDMI Output | Compliant with HDMI 1.3，HDCP2.0 |
| Transmission Distance | 1080P 8-bit 120m(Maximum) over single CAT5E/6 /24AWG/Solid |
| Power consumption | 13.5watts(Maximum) |
| Dimension (L×W×H) | 163x126x26mm |
| Net Weight | RX 465g,TX 465g |
