• Compatible IEEE802.11a/n, HDMI1.3a Standard
• Support 64/128 bit WPA/WPA2 encryption and security mechanism
• Operation with OSD menu, high quality transmission, flexible connection
• Fully compatible with Windows XP and Windows 7
• Data transmission rate is up to 300Mbps
• Transmit high-resolution images(1080p) can up to 20 meters LOS(Line of sight)
• Strong capability to transmit through walls
• Support SSID Broadcast Control
• Plug & Play, Auto setup and easy-to-use

Mode	TX	RX
Freguency Band	5 GHz
Standards	IEEE 802.11n、IEEE 802.11a, HDMI 1.3a
Antenna Type	External omni-directional antenna
Interface	USB Dongle	HDMI1.3
OS	Windows XP / Windows 7
Resolution	640x480@85fps,800x600@85fps,1024x768@75fps,1280x1024@60fps, 1600x1200@30fps720x480@60fps,1280x720@60fps,1920x1080@30fps
Security	WPA /WPA2
Transmission Distance	up to 50m(open site)
Connector	USB	HDMI
Power Supply	5Volt DC provided by USB of PC	5V/2A
Dimensions	100 x 47 x 16mm	140 x 88x 30mm
Weight	27g	139g
